Datasheet
DIGITUS USB 3.2 Gen1 CAT Extender, 5 Gbps, 4 ports:
3x USB-A / 1x USB-C, 100m
DA-73121
EAN 4016032502111
USB Extender, USB 3.2 Gen1, 100m 3x USB-A & 1x USB-C, For use
with CAT cable
This USB extender provides a reliable solution to transmit USB signals
over distances of up to 100 meters using a CAT 6A (or higher) network
cable (not included) without signal loss. Ideal for use in large offices,
conference rooms, surveillance systems or industrial environments
where longer USB connections are required. The USB 3.2 Gen1
standard enables transfer rates of up to 5 Gbps. Nothing stands in the
way of a fast and smooth connection of various USB devices such as
cameras, hard disks, printers, scanners, keyboards, mice and USB
sticks. Thanks to the support of USB 2.0 and 1.1, older devices can also
be integrated without any problems. The extender offers maximum
flexibility thanks to its four USB inputs (3x USB-A 3.2 Gen1 and 1x
USB-C 3.2 Gen1), allowing multiple devices to be operated
simultaneously - ideal for working environments with different
peripherals. The Power-over-Cable (PoC) function ensures that only
the receiver requires an external power source, simplifying installation
and eliminating cable clutter. The Plug & Play design enables easy
installation without the need for additional drivers. In addition, the
robust metal housing ensures durability and stability, even in
demanding industrial environments. Say goodbye to the limitations of
traditional USB cables - with this Digitus USB 3.2 Gen1 Extender you
can place your USB devices where you need them without
compromising on performance.
Overcome the limitations of USB cable lengths and reliably
connect up to four USB devices over distances of up to 100m with
a CAT 6A (or higher) cable. The extender offers high data rates
and is ideal for offices, industry and conferences.
• Maximum range: 100m via Cat 6A (or higher)
• USB ports: 4x USB 3.1 Gen1 inputs (3x USB-A 3.2 Gen1, 1x USB-C
3.2 Gen1)
• Transfer rate: Up to 5 Gbps (USB 3.2 Gen1)
• USB 3.2 Gen1 receiver amplifier reduces signal loss
• Protection: ESD protection (electrostatic discharge), overvoltage
and lightning protection, short-circuit protection
• With its own power supply, so no external power source is required
• Plug & Play: Simple installation, requires no software
• Ideal for connecting remote devices, e.g. cameras, printers, hard
disks, scanners, keyboards, etc.
• Transmitter unit (TX) connections:
• 1x USB-C input (USB 3.2 Gen1) - connection signal source
(notebook, etc.)
• 1x RJ45 output (Gigabit Ethernet) - CAT transmission cable
connection
• 2x status LED
• Receiver unit connections (RX):
• 4x USB output (USB 3.2 Gen1) - 3x USB-A & 1x USB-C connection
mouse, hard disk, keyboard, printer, cameras, etc.
• 1x RJ45 input (Gigabit Ethernet) - CAT transmission cable
connection
• 1x power supply connection (DC 12V/3A) - external power supply
connection
• 2x status LED
• Power supply:
• TX: Via source device
• RX: DC 12V/3A
• Power consumption:
• TX: ≤ 8W
• RX: ≤ 8W
• Operating temperature: -20°C to 60°C
• Power consumption: TX approx. 3.5 W, RX approx. 2.5 W
• Dimensions (per unit): L 8.5 x W 7.6 x H 2.5 cm
• Weight: TX 168g, RX 178g
• Housing material: metal
• Color: Black
Package contents
• 1x transmitter unit
• 1x transmitter unit
• 1x USB 3.2 Gen1 cable 1m, USB-A - USB-C
• 1x USB 3.2 Gen1 cable 1m, USB-C - USB-C
• 1x power supply unit (DC 12V/3A) 1.2m
• 1x fixing material for wall mounting (brackets, screws)
• 2x earthing screw
• 1x operating instructions
www.digitus.info Druckfehler, Irrtümer und technische Änderungen sind vorbehalten. | Printing errors, falsities and technical changes remain reserved. 1
