Rotary & Tilting VESA-Compatible Mount
with Universal Security Enclosure (Black)
USER MANUAL
PAD-PARABRH
1. Mounting Options:
2. Adjusting the Ball Joint:
x1
x4
Contents:
Instructions:
888-733-4448
888-733-4448
x1
1 - Unlock the tablet enclosure by rotating the key
until it pops open
2 - Find the appropriate size included foam pad-
ding for the tablet you wish to use. Make sure
device is compatible for the enclosure
3- Lay your device in and connect any cables or
cords you may have
4 - If needed, make sure to lay-in
the correct masking cover. Then
close and lock the enclosure and
you’re ready to go.
3. Setting up Enclosure and Tablet
x1
x1
x4
x4
*Disclaimer
DO NOT ATTEMPT TO MOVE JOINT WHEN BALL JOINT IS TIGHTENED. FAILURE TO COMPLY WILL RESULT IN
PRODUCT INTEGRITY AND NOT OPERATING AT FULL CAPACITY. RESPONSIBILITY WILL BE ON USER IF PRODUCT
MALFUNCTIONS IN ANY SHAPE OR FORM.
*Mounting a VESA Connection on the
adjustable joint VESA plate example
*Mounting to a Stud Wall*Mounting to a Solid Concrete/Block Wall
*Rotate Counter Clockwise
to loosen Ball Joint
*Adjust the VESA connection and the object
fixed to the VESA to desired tilt and angle
*Rotate Clockwise to tighten and put
the joint in a static state for use.
Problemløsning CTA Digital PAD-PARABRH
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 239 mm |
| Dybde: | 130 mm |
| Højde: | 307 mm |
| Vægt: | 2409 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Sort |
| Panel montering grænseflade: | 75 x 75, 100 x 100 mm |
| Monteringstype: | Væg |
| Kapabilitet: | iPad 10.2-inch (7th/ 8th/ 9th Generation), 11-inch iPad Pro (2018/2020), iPad Air 3 (2019), iPad Air 4 (2020) iPad Gen. 5 (2017), iPad Gen. 6 (2018), iPad Pro 9.7, iPad Pro 10.5, iPad Air Gen. 1-2, Galaxy Tab A 9.7”, Galaxy Tab S2 9.7”, Galaxy Tab S3 9.7”, Galaxy Tab 3 10.1”, and Galaxy Tab 4 10.1”, Galaxy Tab A 10.1″ (2019), Galaxy Tab A 10.1″ (2016), Lenovo Tab 4, Surface Go, Galaxy Tab S5E, Galaxy Tab S6/Lite |
| Låsetype: | 2 nøgler |
| Monteringsbeslag inkluderet: | Ja |
| Skruer inkluderet: | Ja |
| Maksimal skærmstørrelse kompatibilitet: | 11 " |
| Minimal skærmstørrelse kompatibilitet: | 9.7 " |
| Farvegruppe: | Sort |
| Antal nøgler inkluderet: | 2 stk |
