Side 1/4
Connect Frame to Tent
– Insert one end of main tent pole
onto pin of pin & ring system at tent
corner. (illus. 3)
– Go to opposite end of pole and
gradually apply pressure to the pole
forming an arch until you are able to
insert the pin into the pole.
– Repeat for second pole. (illus. 4)
1
Layout & Positioning
of Tent, Pole Assembly
– Layout and position tent with door
facing desired direction. (illus. 1)
– Unzip door.
– Stake down tent using the rings of the
pin & ring system at the corners of the
tent. Keep the floor taut. (illus. 2)
– Assemble frame poles by
interlocking shock-corded poles.
This will make two long poles.
– Insert the poles diagonally into pole
sleeves.The center of the poles should
cross forming an “X” in the middle of
tent. (illus. 1)
2
Assembled poles
inserted through
pole sleeves
illus. 1
illus. 4
Tent frame set-up
illus. 2
Tent stake through ring
illus.3
Insert pole end onto
pin & ring
SUNDOME
®
7’x7’
When You Are Ready To Set
Up Your Tent
–
Select a level campsite clear of
rocks, branches and other hard
or sharp objects.
– Do not set up your tent under trees.
–
For best results in windy conditions,
do not position the door of tent
into the wind.
Rainfly
Pole
Rainfly Part No.
9180-3041
Main Tent
Poles
POLE ASSEMBLY PARTS
Instructions apply to Part Number 2000001114
Part No. 9180-3061
Part No. 9180-3051
Problemløsning Coleman Sundome
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Strandtelt |
| Vægt: | 1900 g |
| Ramme, materiale: | Glasfiber |
| Pakkens dimensioner (BxDxH): | 510 x 110 x 110 mm |
| Bæretaske: | Ja |
| Formål: | Strand |
| Rammetype: | Hård ramme |
| Brandspecifikke teknologier: | Coleman WeatherTec |
| Antal sovepladser: | 2 person(er) |
| Bedømmelse af vandtæt teltstof: | 500 mm |
| Flammehæmmende lærred: | Ja |
| Materiale for udvendig overflade: | Polyester |
