12” (30.5cm) SUBWOOFER
Lightweight Reinforced Cone
High Strength Stamped Steel Basket
High Temperature Nomex Spider
Heavy Duty Copper Voice Coil
High Power 65 oz Strontium Ferrite Magnet
High Excursion NBR Surround
Kapton Voice
Coil Former
Fiber Dust Cap
Aluminumized Composite Dust Cap
11-11/16''DIA
Gold Plated Terminal
Air Cooling Voice Coil Chamber
Formed Top Plate
Internal Area cu. ft. (liter) 1.25 (35.40) Internal Area cu. ft. (liter) 2.0 (56.63)
-3dB Point (Hz) 40 -3dB Point (Hz) 28
Qtc Enclosure Damping 0.81 Tuning Frequency (Hz) 32
H Height -inch (cm) 14 (35.56) H Height -inch (cm) 13.5 (34.29)
W Width -inch (cm) 24 (60.96) W Width -inch (cm) 16.5 (41.91)
D Depth -inch (cm) 10 (25.40) D Depth -inch (cm) 23 (58.42)
P Port Diameter and Length -inch (cm) 4 x 13.2 (10.16x33.53)
Ported Enclosure RecommendationSealed Enclosure Recommendation
NOTE: Internal volume is measured before speaker and/or port displacement. External dimensions are based on the use of 3/4”
(1.9cm) material. The port can be placed on any fitting face as long as the port ends are not obstructed. When using enclosures
other than recommended, contact technical support or your local installation expert. Proper enclosure design is one of the key
components to subwoofer performance and should be handled by experienced installers. Please contact your authorized Clarion
dealer for the best results.
V
b
V
b
F
3
F
3
F
b
1/4''
6-3/8''
12-9/32''DIA
11-1/32''DIA
Maximum Musical Input Power 900W F
o
Resonance Frequency 23Hz
Continuous Input Power 300W V
as
Equivilant Stiffness 64.3L
Sensitivity 83dB Q
ts
Total Electromechanical Dampening 0.56
Impedance 4 ohms S
d
Cone Area 530.9 cm²
Thiele / Small Electromechanical ParametersElectrical Specifications
