Installation and Wire
connection manual
VRX928RVD
Installation and Wire connection manual
■ Contents
1. BEFORE STARTING ............................................................... 65
2. PACKAGE CONTENTS ........................................................... 65
3. GENERAL CAUTIONS ............................................................ 66
4. CAUTIONS ON INSTALLATION .............................................. 66
5. INSTALLING THE MAIN UNIT ................................................. 67
6. REMOVING THE MAIN UNIT .................................................. 69
7. CAUTIONS ON WIRING .......................................................... 69
8. WIRE CONNECTION .............................................................. 70
9. SAMPLE SYSTEMS ................................................................ 73
1. BEFORE STARTING
2. PACKAGE CONTENTS
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “-” termi-
nal before starting. This is to prevent short
circuits during installation. (Figure 1)
Car battery
Figure 1
1 Main unit
2 Tuner Amp unit
3 Manuals
Owner’s manual & Installation manual
Warranty card
4 Power supply lead (For the main unit)
5 Power supply lead (For the tuner amp
unit)
6
Connection cord (Main unit ↔ Tuner amp unit)
7 Antenna extension cord
8 RGB connecting cord
9
Bag for accessories of the main unit (No. 1)
Flat head screw (M5 × 8) ............................ 4
Sems hexagonal bolt (M5× 8) ..................... 5
Electro tap
Machine screw (M4× 3)............................... 4
0
Bag for accessories of the main unit (No. 2)
Hook plate ................................................... 2
Cord clamp
Rubber cap
Special screw
! Bag for accessories of tuner amp unit
Maunting bracket......................................... 2
Canoe clip ................................................... 4
Machine screw (M4 × 8) .............................. 4
@ Universal mounting bracket
# Remote control unit
$ Battery
(for remote control unit)
% Outer Escutcheon
¥ DCP Case
