T
russ
Pitch-Adjustable (TPP) Mount
BEFORE YOU BEGIN
• WARNING: TO PREVENT PERSONAL INJURY, THOROUGHLY STUDY ALL INSTRUCTIONS AND ILLUS-
TRATIONS BEFORE YOU BEGIN TO INSTALL THE UNIT. PAY PARTICULAR ATTENTION TO THE “IMPOR-
TANT WARNINGS AND CAUTIONS” ON PAGE 1.
• CAUTION: To prevent damage to the mount, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install the unit. Pay particular attention to the
“IMPORTANT WARNINGS AND CAUTIONS” on Page 1.
• The maximum weight to be installed on the TPP is 150 pounds (68.04 Kg).
• If you have any questions about this assembly, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480.
I N S T R U C T I O N M A N U A L
The Truss Pitch-Adjustable (TPP) mount is a perfect
solution exhibit, retail and digital signage applications.
The mount is quick, easy and versatile.
The TPP accommodates a large range of truss dimen-
sions (up to 14” O.D.), includes security options and pro-
vides flexible feature to achieve a custom installation
installation. The exclusive Q-Latch™ Mounting System
secures the LArge Flat Panel Display with a lockable
latch to confirm mount stability and integrated security
allows the display to be locked to the mount by adding a
padlock.
Your display can be mounted portrait or landscape and
four pitch adjustments, up or down, are available as pre-
set, locking positions (0, 5, 10 or 15 degrees).
LOGO
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY
SAVAGE, MINNESOTA 55378 USA
PART NO. 8804-000010 (Rev. B)
©2003 Chief Manufacturing
www.chiefmfg.com
Printed in USA 05-04
Problemløsning Chief TPP2534
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 433 mm |
| Dybde: | 105 mm |
| Højde: | 412 mm |
| Brugervejledning: | Ja |
| Produktfarve: | Sort |
| Monteringstype: | Væg |
| Hældningsvinkelområde: | 5 - 15 ° |
| Dybde (efter britisk standard): | 4.1 " |
| Højde (efter britisk standard): | 16.2 " |
| Bredde (efter britisk standard): | 17.1 " |
| Skærmstørrelse kompatibilitet: | 42 - 71 " |
| Maksimal vægtkapacitet: | 68 kg |
| Maksimal skærmstørrelse kompatibilitet: | 71 " |
| Minimal skærmstørrelse kompatibilitet: | 42 " |
