INSTALLATION INSTRUCTIONS
CHIEF MANUFACTURING INC. 8805-000239
1-800-582-6480 952-894-6280 FAX 952-894-6918 2007 Chief Manufacturing
8401 EAGLE CREEK PKWY, STE. 700 www.chiefmfg.com
SAVAGE, MINNESOTA 55378 USA 09/07
DISPLAY STATIC MOUNT
PSM-2029
(1) Plasma Static Mount (4) Mounting Buttons – Clear Zinc
(4) M6 x 25mm Phillips Head Screw (1) Nylon Washer
(1) Latching Flag (1) 10-24 Nylock Nut
(1) 10-24 x .5 Flat Head Undercut Screw
BEFORE PROCEEDING: Unpack the carton, verify contents shown in Figure 1 and read
installation instructions completely. If you are missing any of the listed components, please
contact Customer Service at 1-800/582-6480.
Plasma Displays are Extremely Fragile.
1. Attach latching flag to mount using the 10-24 Phillips flat head screw, Nylon washer, and
Nylock nut (see Figure 2). Tighten until friction will hold the flag in place.
2. Attach mounting buttons to display using four M6 screws provided (see Figure 3 &
Figure 4).
CAUTION!
Figure 2
Figure 1
Figure 3 Figure 4
Problemløsning Chief PSM2043
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Produktfarve: | Sort |
| Husmateriale: | Metal |
| Monteringstype: | Væg |
| Skærmstørrelse kompatibilitet: | 65 " |
| Maksimal vægtkapacitet: | 79.38 kg |
