Chief, a products division of
Milestone AV Technologies
6436 City West Parkway, Eden Prairie, MN 55344
• P: 800.582.6480 / 952.225-6000 • F:877.894.6918 / 952.894.6918
8800-002338 Rev.01
©2016 Milestone AV Technologies
www.milestone.com
08/16
INSTALLATION INSTRUCTIONS
Small Flat Panel Mounts
Model: K-Series
This Instruction Manual covers most of the K-Series wall,
desk, and pole mounts for single, dual, and triple
displays. In addition, this Instruction Manual also covers
selected K-Series accessories.
NOTE: Some K-Series mounts, such as Extreme Tilt,
Grommet, and Table, as well as most K-Series
accessories, have separate Instruction Manuals.
See Specifications for a complete list of models
covered by this Instruction Manual.
NOTE: If an accessory such as an optional laptop tray is
being installed, complete all required installation
procedures within this document prior to installing
the accessory.
K-Series Mounts (Examples)
Problemløsning Chief KWS220S
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 694 mm |
| Dybde: | 163 mm |
| Højde: | 368 mm |
| Produktfarve: | Sort |
| Monteringstype: | Væg |
| Hældningsvinkelområde: | 15 - -15 ° |
| Maksimal vægtkapacitet: | 15 kg |
| Maksimal skærmstørrelse kompatibilitet: | 24 " |
| Minimal skærmstørrelse kompatibilitet: | 10 " |
| Montering interface kompatibilitet (min.): | 100 x 100 mm |
| Montering interface kompatibilitet (maks.): | 100 x 100 mm |
