Brother MFC-L6915DN Brugsanvisning
Her er Brother MFC-L6915DN (Faxmaskine) brugervejledning. 2 sider på sprog med en vægt på 622,494.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
Unpack the machine and check the components
AC Power Cord
USB Port Cover
(Not included in all models)
Toner Cartridge and Drum Unit
Assembly
(Installed in the machine)
Quick Setup Guide Product Safety Guide
1
Remove the packing materials and re-install the toner cartridge and drum unit assembly
Remove the orange part.
2
Load paper in the paper tray
Adjust the paper
guides.
Do not exceed this mark.
Discard the
silica gel pack.
3
Connect the power cord and turn the machine on
Back Front
NOTE:
Before connecting the power cord,
locate the Serial Number label on
the back or side of the machine.
Record this number for Registration
and Warranty support.
NOTE:
• The components included in the box may differ depending on your
country.
• The available connection interfaces vary depending on the model.
You must purchase the correct interface cable if you require one.
• USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no more
than 2 metres long.
• Network cable
Use a straight-through Category 5 (or greater) twisted-pair cable.
• The screens and images in this show the Quick Setup Guide
MFC-L6915DN.
• Brother aims to reduce waste and save both raw materials and the
energy required to produce them.
Read more about our environmental work at www.brotherearth.com.
4
Select your country/language
(Initial setup only)
After turning the machine on, you may be required
to set your country or language (depending on your
machine).
If required, follow the on-screen instructions.
Quick Setup Guide
Read the for the correct installation procedure.Product Safety Guide Quick Setup Guidefirst,thenreadthis
Not all models are available in all countries.
The latest manuals are available at the Brother support website:
support.brother.com/manuals
Video setup instructions:
support.brother.com/videos
EN
DCP-L5510DW / MFC-L5710DN / MFC-L5715DN / MFC-L5710DW / MFC-L6710DW /
MFC-L6910DN / MFC-L6915DN / MFC-EX910
D0296N001-00
UK
Version 0
Problemløsning Brother MFC-L6915DN
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 495 mm |
| Dybde: | 495 mm |
| Højde: | 518 mm |
| Vægt: | 18100 g |
| Produktfarve: | Hvid |
| Kontroltype: | Berøring |
| Indbygget skærm: | Ja |
| Pakkevægt: | 24000 g |
| Pakkedybde: | 580 mm |
| Pakkebredde: | 588 mm |
| Pakkehøjde: | 628 mm |
| USB-port: | Ja |
| Antal USB 2.0-porte: | 2 |
| Ethernet LAN: | Ja |
| Udskrivningsteknologi: | Laser |
| Maksimal opløsning: | 1200 x 1200 dpi |
| Udskrivningshastighed (sort, normal kvalitet, A4/amerikansk papirformat): | 50 sider pr. minut |
| Udskrivning: | Monoprint |
| Medietyper til papirbakke: | Bond paper, Envelopes, Letterhead, Plain paper, Recycled paper, Thicker paper, Thin paper |
| Maksimal ISO A-serie papirstørrelse: | A4 |
| ISO A-serie, størrelser (A0...A9): | A4, A5, A6 |
| Ikke-ISO udskriftsmedier størrelse: | Legal (media size), Letter (media size) |
| Kuverter størrelser: | C5, Com-10, DL, Monarch |
| Samlet antal inputbakker: | 1 |
| Samlet inputkapacitet: | 520 ark |
| Samlet outputkapacitet: | 250 ark |
| Scanner type: | ADF-scanner |
| Scanningsteknologi: | Dual CIS |
| Optisk scanningsopløsning: | 1200 x 1200 dpi |
| Scanning: | Mono scanning |
| Kopiering: | Monokopiering |
| Maksimal kopiopløsning: | 1200 x 600 dpi |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Sikkerhedsalgoritmer: | 64-bit WEP, 128-bit WEP, APOP, SMTP-AUTH, SNMPv3, SSL/TLS, WPA-AES, WPA-PSK, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPA3-SAE |
| Markedspositionering: | Forretning |
| Direkte udskrivning: | Ja |
| USB-stik: | USB Type-A / USB Type-B |
| Strømforbrug (slukket): | 0.05 W |
| Maksimal driftscyklus: | 16000 sider pr. måned |
| Udskrivning af farver: | Sort |
| Fax: | Monofaxing |
| Intern hukommelse: | 2000 MB |
| Near Field Communication (NFC): | Ja |
| Modemhastighed: | 33.6 Kbit/s |
| Duplex udskrivning: | Ja |
| Duplex udskrivningstilstand: | Automatisk |
| Duplex-funktioner: | Copy, Fax, Print, Scan |
| Antal printpatroner: | 1 |
| Strømforbrug (udskrivning): | 710 W |
| Tid til første side (sort, normal): | 6.7 sek./side |
| Kopieringshastighed (sort, normal kvalitet, A4): | 50 Kopier pr minut |
| Duplekskopiering: | Ja |
| Duplex scanning: | Ja |
| Dupleksfax: | Ja |
| Sidebeskrivelsessprog: | BR-Script 3, IBM ProPrinter, PCL 6 |
| Strømforbrug (dvale): | 6.7 W |
| Sikker udskrivning: | Ja |
| Universal-magasin kapacitet: | 100 ark |
| Multifunktionsbakke: | Ja |
| Energy Star-typisk elektricitetsforbrug (TEC): | 0.63 kWh/uge |
| Scan til: | E-mail, E-mail Server, FTP, OCR, USB |
| Strømforbrug (klar): | 31 W |
| Automatisk dokumentføder (ADF): | Ja |
