Bosch SMS4HMI00G Brugsanvisning
Her er Bosch SMS4HMI00G (Opvaskemaskine) brugervejledning. 2 sider på sprog med en vægt på 655,790.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
9001720903 (020405) SMS4HMI00G
*9001720903* Quick reference guide Dishwasher
en
Before using for the first time, read the instruction manual and the safety information it contains.
Setting up Home Connect
Tip:Connect your appliance to a mobile device. You can con-
veniently change all settings using the HomeConnect app.
1.
Install the HomeConnect app on your mo-
bile device and follow the instructions.
2.
Scan the QR code with the HomeConnect
app.
Overview of water hardness settings
You can find an overview of the
water hardness values that can
be selected here.
A table of country-specific units
can be found in the instruction
manual.
Hardness
range
mmol/l Setting
value
Soft 0 - 1.1 H00
Soft 1.2 - 1.4 H01
Medium 1.5 - 1.8 H02
Medium 1.9 - 2.1 H03
Medium 2.2 - 2.9 H04
Hard 3.0 - 3.7 H05
Hard 3.8 - 5.4 H06
Hard 5.5 - 8.9 H07
Setting the water softening sys-
tem
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
aThe display shows Hxx.
aThe display shows .
3.
Press repeatedly until the right
water hardness has been set.
4.
To save the settings, press
for 3 seconds.
Adding special salt
To avoid damage to the appliance, only add special
salt to the dispenser for special salt just before the
programme starts.
1.
Unscrew the lid of the dispenser for special salt
and remove.
2.
On initial start-up: Fill the dispenser right up with
water.
3.
Add the special salt to the
dispenser. The water in the
dispenser is displaced and
forced out. Never add de-
tergent.
4.
Place the lid back on the dispenser and turn to
close.
Adding rinse aid
1.
Press the catch on the lid
of the dispenser for rinse
aid and lift .
1
2
2.
Add rinse aid up to the
max mark.
max
3.
Close the lid of the dispenser for rinse aid.
aThe lid clicks into position.
How to use your appliance
1.
Load the tableware.
Only clean tableware that is suitable for dish-
washers. Remove large remnants of food from
the tableware. Check that the spray arms can ro-
tate freely.
2.
Add detergent.
3.
Switch on the appliance .
4.
Select the programme.
5.
Start the programme .
6.
Remove the tableware at the end of the pro-
gramme.
7.
To cancel the programme, press for
approx. 4seconds.
The programme is cancelled and ends after ap-
prox. 1minute.
Programmes
The programme data has been meas-
ured in the laboratory according to
European standard EN60436.
The consumption figures depend on
the programme and additional func-
tion selected.
The runtime will change if the rinse
aid system is switched off or rinse aid
needs to be added.
Programme 1) Duration [h:min]
2) Energy [kWh]
3) Water [l]
Intensive 70°
1) 2:05 -2:15
2) 1,300 -1,400
3) 11,5 -14,0
Auto 45-65°
1) 1:40-2:45
2) 0,900-1,500
3) 7,0-15,5
Eco 50°
1) 4:55
2) 0,849
3) 9,5
Silence 50°
1
1) 4:00
2) 1,050
3) 11,0
Express 65° - 1h
1) 1:00
2) 1,300
3) 10,5
Machine Care
1) 2:10
2) 1,350
3) 15,2
Favourite
1) 0:15-0:15
2) 0,050-0,050
3) 4,0-4,0
1
Suitable programme for running at night: it
takes longer, but is extremely quiet.
Adding detergent
1.
Add the detergent to the
dry detergent dispenser.
15 ml
25 ml
50 ml
2.
Close the lid of the deter-
gent dispenser.
aThe lid clicks into position.
Problemløsning Bosch SMS4HMI00G
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 220-240 V |
| Vekselstrømsindgangsfrekvens: | 50-60 Hz |
| Bredde: | 600 mm |
| Dybde: | 600 mm |
| Højde: | 845 mm |
| Vægt: | 50300 g |
| Kontroltype: | Knapper |
| Indbygget skærm: | Ja |
| Strøm: | 10 A |
| Ledningslængde: | 1.75 m |
| Pakkevægt: | 51900 g |
| Understøttelse af Smartphone-fjernbetjening: | Ja |
| Placering af apparat: | Fritstående |
| Tilsluttet belastning: | 2400 W |
| Støjniveau: | 44 dB |
| Tilløbsslange, længde: | 1.65 m |
| Antal vaskeprogrammer: | 6 |
| Forsinket start-timer: | Ja |
| Justerbare fødder: | Ja |
| Justering af fødder: | 20 mm |
| Understøttede scanningstilstande: | 1155 mm |
| Dør farve: | Rustfrit stål |
| Balje materiale: | Rustfrit stål |
| Vandforbrug pr. cyklus: | 9.5 L |
| Bestik rum type: | Skuffe |
| Farve på kontrolpanel: | Sølv |
| Antal kuverter: | 14 kuverter |
| Cyklustid: | 295 min. |
| Forsinket start (maks.): | 24 t |
| Opvaskeprogrammer: | Eco 50°C, Silent 50°C, Express, Favorite, Intensive 70°C, Auto 40-65°C |
| Halv belastning: | Ja |
| Automatisk detektering af vaskemiddel: | Ja |
| Indikator for afspændingsmiddel: | Ja |
| Energieffektivitetsskala: | A til G |
| Selvrensende: | Ja |
| AquaStop funktion: | Ingen |
| Glasbeskyttelse: | Ja |
| Indikator for resterende tid: | Ja |
| Udøsslange længde: | 1.9 m |
| Produktstørrelse: | Fuld størrelse (60 cm) |
| Wi-Fi kontrolleret: | Ja |
| Overløbsbeskyttelse: | Ja |
| Støjemissionsklasse: | B |
| Energieffektivitetsklasse: | D |
| Energiforbrug pr. 100 cyklusser: | 85 kWh |
| Brugerdefineret panel klar: | Ingen |
| Temperatur (maks): | 70 °C |
| Saltindikator: | Ja |
| Øverste kurv indstillelig højde: | Ja |
| Kurves indstillelige placering: | Øvre |
| Doseringsassistent: | Ja |
| Selvrensende filter: | Ja |
| Tørresystem: | Varmeveksler |
| Ekstra tørt: | Ja |
| Antal kurve: | 2 kurv(e) |
| Aftagelig overside: | Ja |
| Bestikkkurv type: | Bosch VarioDrawer |
| Kontrol apps understøttes: | Bosch Home Connect |
| Aftagelig bestikkurv: | Ja |
