Bosch DIVAR IP all-in-one 5000 Brugsanvisning
Her er Bosch DIVAR IP all-in-one 5000 (Server) brugervejledning. 5 sider på sprog Engelsk med en vægt på 0.4 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/5
Video | DIVAR IP all-in-one 5000
DIVAR IP all-in-one 5000
www.boschsecurity.com
uAll-in-one, fully featured video recording and
management solution for up to 42 channels
uOut-of-the-box IP video recording with up to 48 TB
(4 x 12 TB) storage capacity pre-installed
uRobust, secure operation — instant real time access
to video
uAdvanced user and alarm management
u3 years warranty, including parts replacement within
3 business days services
The DIVAR IP all-in-one 5000 appliance is an affordable
and easy to use all-in-one recording, viewing, and
management solution for network surveillance systems
of up to 42 channels (with 8 channels pre-licensed).
Running the full BVMS solution and powered by
Bosch Video Recording Manager including the
Video Streaming Gateway to integrate third-party
cameras, it is an intelligent IP video management and
storage device.
DIVAR IP all-in-one 5000 is a 4-bay mini tower unit that
combines advanced management and state-of-the-art
recording management into a single cost-effective,
plug and play IP recording appliance for IT-minded
customers.
System overview
The DIVAR IP all-in-one 5000 appliance utilizes a highly
energy efficient, embedded design which boasts
Bosch quality through-and-through.
Easy to install and operate, the system features
wizard-based set-up and centralized configuration. All
components are pre-installed and pre-licensed. Simply
connect to the network and power the unit up -
DIVAR IP all-in-one is ready to begin recording straight
out of the box.
BVMS manages all IP and digital video and audio, plus
all the security data being transmitted across your IP
network. It seamlessly combines IP cameras and
encoders, provides system-wide event and alarm
management, system health monitoring, user and
priority management.
Functions
DIVAR IP all-in-one 5000 features front-swappable
SATA hard drives providing up to 48 TB of gross
storage capacity. All system software is pre-installed —
creating an out-of-the-box ready-to-use video
management appliance. DIVAR IP all-in-one 5000
utilizes Microsoft Windows Storage Server 2016 (64-
bit).
Instant real time access to video
View high quality HD or even UHD video despite low or
limited bandwidth connections. Dynamic Transcoding
technology ensures you can view your video
immediately — anytime, anywhere.
Dynamic Transcoding decodes and re-encodes the
data stream to a lower rate bit stream tailored to the
bandwidth of the connection.
When the video is paused, the instant detail
enhancement feature instantly displays the full
resolution video.
Problemløsning Bosch DIVAR IP all-in-one 5000
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | NAS |
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50/60 Hz |
| Bredde: | 210 mm |
| Dybde: | 279 mm |
| Højde: | 240 mm |
| Vægt: | 6800 g |
| Produktfarve: | Sort |
| USB-port: | Ja |
| Opbevaringstemperatur (T-T): | -40 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 8 - 90 % |
| Relativ luftfugtighed ved opbevaring (H-H): | 5 - 95 % |
| Antal HDMI-porte: | 1 |
| Ethernet LAN-porte (RJ-45): | 2 |
| Antal USB 2.0-porte: | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 2 |
| Ethernet LAN: | Ja |
| Processorkerner: | 4 |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Intern hukommelse: | 8 GB |
| Processorfrekvens: | 3.6 GHz |
| Processorserie: | Intel® Core™ i3 |
| Processortråde: | 4 |
| Processor-cache: | 6 MB |
| Processor cache type: | Smart cache |
| Intern hukommelsestype: | DDR |
| On-board grafikkort, model: | Intel® UHD Graphics 630 |
| Intel® Hyper Threading Teknologi (Intel® HT Technology): | Ingen |
| Intel® Turbo Boost Teknologi: | Ingen |
| Processorproducent: | Intel |
| Processormodel: | i3-8100 |
| Antal DisplayPorts: | 1 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte: | 2 |
| Enhanced Intel SpeedStep Teknologi: | Ja |
| Udfør deaktivering af bit: | Ja |
| Idle status: | Ja |
| CPU-konfiguration (maks.): | 1 |
| Intel® VT-x with Extended Page Tables (EPT): | Ja |
| Indlejret tilgængelige muligheder: | Ja |
| Intel® 64: | Ja |
| Intel® Virtualization Technology for Directed I/O (VT-d): | Ja |
| Intel® Virtualization Technology (VT-x): | Ja |
| Grænseflade til lagerdisk: | SATA |
| Størrelse på lagerdisk: | 3.5 " |
| Antal understøttede lagerdiske: | 4 |
| Datalagringsdriver installeret: | Ja |
| Bus type: | DMI3 |
| Processorgeneration: | 8th gen Intel® Core™ i3 |
| Kabinettype: | Mini Tower |
| Intel® Trusted Execution Teknologi: | Ingen |
| Intel® Enhanced Halt State: | Ja |
| Intel® TSX-NI: | Ingen |
| Intel® Stabil Billede Platformsprogram (SIPP): | Ingen |
| Intel® klar video teknologi: | Ja |
| Intel® Identity Protection Technology version: | 1.00 |
| Intel® Secure Key Technology version: | 1.00 |
| Intel® Stable Billede Platform Program (SIPP) version: | 0.00 |
| Intel® TSX-NI-version: | 0.00 |
| Konfliktfri processor: | Ja |
| Processor sokkel: | LGA 1151 (stik H4) |
| Processor litografi: | 14 nm |
| Thermal Design Power (TDP): | 65 W |
| Maksimalt antal PCI Express-kanaler: | 16 |
| PCI Express slots version: | 3.0 |
| PCI Express-konfigurationer: | 1x16,1x8+2x4,2x8 |
| Tjunction: | 100 °C |
| Systembus-hastighed: | 8 GT/s |
| Processor driftstilstande: | 64-bit |
| Processor kodenavn: | Coffee Lake |
| Intel® InTru™ 3D Teknologi: | Ja |
| Intel® Clear Video HD Teknologi (Intel® CVT HD): | Ja |
| Intel® Sikker Nøgle: | Ja |
| Intel® Identity Protection Teknologi (Intel® IPT): | Ja |
| Intel® Quick Sync Video Teknologi: | Ja |
| Intel® AES Nye Instruktioner (Intel® AES-NI): | Ja |
| Intel® OS Guard: | Ja |
| Termiske overvågningsteknologier: | Ja |
| Intel® Clear Video Teknologi til MID (Intel® CVT for MID): | Ja |
| Processor-pakke størrelse: | 37.5 x 37.5 mm |
| Processor ARK ID: | 126688 |
| Indbygget grafikadapter basefrekvens: | 350 Mhz |
| Indbygget grafikadapter dynamisk frekvens (maks.): | 1100 Mhz |
| Indbygget grafikadapter-ID: | 0x3E91 |
| Maksimalt indbygget grafikadapterhukommelse: | 64 GB |
| Indbygget grafikadapter DirectX-version: | 12.0 |
| Understøtter RAID: | Ingen |
| Understøttede lagerdrev brugerflader: | SATA |
| Antal installerede lagerdiske: | 4 |
| Total installeret opbevaringskapacitet: | 48 TB |
| Kapacitet af datalagringsdrev: | 12000 GB |
| Hot-swap drevbåse: | Ja |
| Maksimal intern hukommelse understøttet af processor: | 64 GB |
| Hukommelsestyper understøttet af processor: | DDR4-SDRAM |
| Hukommelsesbåndbredde understøttet af processor (maks.): | 37.5 GB/sek. |
| Indbygget grafikadapter OpenGL-version: | 4.5 |
| Antal understøttede skærme (indbygget grafik): | 3 |
| Skalerbarhed: | 1S |
| Specifikation for termisk opløsning: | PCG 2015C |
| Antal udførelsesenheder: | 23 |
| Understøttede lagerdisk størrelser: | 3.5 " |
| Strømforsyningens kapacitet (PCU): | 250 W |
