Atlona
2151 O’toole Ave Unit D
San Jose, CA 95131
Tel: 408-954-8782
Fax: 408-954-8792
toll free: 1-877-536-3976
www.AtlonA.com
AdoPtEr
Compatible with:
Atlona HDMI Digital Cable with Swivel Connectors
Technical Specications:
• 1m (3,3 ft), 2m (6,6ft), 3m (10ft) and 5m (16,5ft) HDMI to HDMI cable
• 24k Gold plated connectors
• Supports high resolutions up to 1080p or 1920x1200
• High-Purity Oxygen free copper conductors
• High-density triple shielding for maximum rejection of EMI and RFI
• Available in White color only.
• Lifetime warranty
SKU# Weight
ATP-14035-1 1.00 lbs
ATP-14035-2 1.40 lbs
ATP-14035-3 2.00 lbs
ATP-14035-5 2.60 lbs
Features:
• HDMI 1.3b certied cable
• 36bit Deep Color Support
• Extremely high video bandwidth 382 MHz (over 10.2 Gbit/s)
• Supports all digital audio formats including Dolby TrueHD and DTS-HD Master Audio
• Supports high resolutions up to 1080p or 1920x1200
• The cable is based on Oxygen Free Copper and therefore delivers perfect video without
any degradation
• The HDMI connectors are able to swivel 180-degrees which allows proper connection
to be made without bending an actual cable
• 24k gold-plated connectors ensure maximum conductivity
• High-density triple shielding for maximum rejection of EMI and RFI
Problemløsning Atlona AT14035-3
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Produktfarve: | Hvid |
| Maksimal opløsning: | 1920 x 1200 pixel |
| Certificering: | RoHS |
| Kabellængde: | 3 m |
| Plug and play: | Ja |
| Stik 1: | HDMI Type A (Standard) |
| Stik 2: | HDMI Type A (Standard) |
| Stikforbindelse kontakter plettering: | Guld |
| Stik køn: | Hanstik/Hanstik |
| Båndbredde: | 382 MHz |
