Installation Guide
AT-VCC-IR3-KIT
1
IP to IR Command Converter for Velocity Control System
AT-VCC-IR3-KIT
The Atlona AT-VCC-IR3-KIT is an accessory for the Atlona Velocity™ Control System that
provides conversion from IP control commands to IR. This Velocity Control Converter is very
compact and can be placed anywhere a device requires IR control. The VCC-IR3-KIT is remotely
powered through Power over Ethernet (PoE), or locally from a USB power source. The primary
unit installs onto any surface via a convenient mounting dock. A simple “click” locks it into place
for a secure, reliable installation. The IR adapter module includes three IR emitters attached by
a 3.5mm cable. Each emitter is independently addressable, allowing discrete IR control of three
dierent AV devices.
1 x AT-VCC
1 x AT-VCC-IR3
Package Contents
Operating Notes
• The AT-VCC-IR3-KIT is PoE, to power the unit, simply plug it into a PoE compatible network
switch. If the network switch is not PoE capable, a PoE injector (purchased separately) or USB
can be used.
• All devices (AT-VCC, Velocity, AT-VTP, switchers, etc) should be set to static IPs or the
DHCP IP address reserved for each individual device.
IMPORTANT: Velocity Gateway (AT-VGW-HW) must be set up before the AT-VCC-IR3-KIT
is fully functional.
Problemløsning Atlona AT-VCC-IR3-KIT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | AV gentager |
| Produktfarve: | Sort |
| Maksimal opløsning: | - pixel |
| Forbindelsesteknologi: | Kabel & trådløs |
| Certificering: | FCC, C-tick, RoHS |
| Netværksstandarder: | IEEE 802.3af |
| Strømkilde type: | USB |
| Strøm over Ethernet (PoE): | Ja |
| RJ-45 indgangs-porte: | 1 |
| IR udsender inkluderet: | Ja |
