Installation Guide
1
AT-RON-442 / AT-RON-444
4K HDR Two / Four-Output HDMI Distribution Amplier
AT-RON-442 / AT-RON-444
The Atlona Rondo™ series are HDMI distribution ampliers for high dynamic range (HDR)
formats. They are HDCP 2.2 compliant and support 4K/UHD video @ 60 Hz with 4:4:4 chroma
sampling, as well as HDMI data rates up to 18 Gbps. The Rondo series are ideal for applications
requiring the latest as well as emerging 4K/UHD and HDR sources and displays. They are
compatible with all video resolutions, audio formats, and color space formats supported in the
HDMI 2.0a specication, plus the ability to pass metadata for HDR content. The Rondo Series
HDMI distribution ampliers include EDID management features, front panel LED indicators
for power and signal status, and the capability to cascade several units without compromising
performance.
Package Contents
AT-RON-442
1 x AT-RON-442
1 x 5V DC power supply
1 x Phoenix terminal block, 2-pin
2 x Rack ears
4 x Rubber feet
4 x Screws
1 x Installation guide
AT-RON-444
1 x AT-RON-444
1 x 5V DC power supply
1 x Phoenix terminal block, 2-pin
2 x Mounting plates
1 x Long rack ear
1 x Short rack ear
4 x Rubber feet
4 x Screws
1 x Installation guide
IMPORTANT: Visit http://www.atlona.com/product/AT-RON-442 and http://www.atlona.
com/product/AT-RON-444 for the latest rmware updates.
Problemløsning Atlona AT-RON-444
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 219.5 mm |
| Dybde: | 253.7 mm |
| Højde: | 44 mm |
| Vægt: | 1390 g |
| Produktfarve: | Sort |
| Understøttede videotilstande: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 90 % |
| HDCP: | Ja |
| Strømforbrug (typisk): | 6.75 W |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Antal: | 1 |
| Certificering: | CE, FCC, Level VI, RoHS, cULus, RCM, CCC |
| Harmoniseret systemkode (HS): | 85176990 |
| Indgangsspænding: | 100 - 240 V |
| Farvedybde: | 12 Bit |
| Maksimal videoopløsning: | 4096 x 2160 pixel |
| Værtsgrænseflade: | HDMI |
| Indgangsfrekvens: | 50 - 60 Hz |
| Output-grænseflade: | HDMI |
| Understøttede opløsninger: | 4096×2160, 3840×2160, 2048×1080 |
| Båndbredde: | 18 Gbit/sek. |
| Konverter type: | Aktiv videoomformer |
| Udvidet display identifikationsdata (EDID): | Ja |
