Atlona AT-OME-EX-WP-KIT-LT Brugsanvisning
Her er Atlona AT-OME-EX-WP-KIT-LT (AV forlænger) brugervejledning. 16 sider på sprog med en vægt på 1,769,387.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/16
1
Installation Guide
AT-OME-EX-WP-KIT-LT
Omega
™
4K/UHD
Wallplate HDBaseT TX/RX for HDMI with USB
AT-OME-EX-WP-KIT-LT
The Atlona AT-OME-EX-WP-KIT-LT is an HDBaseT extender for video up to 4K/60 4:2:0, plus
embedded audio, control, and USB over distances up to 130 feet (40 meters) for 4K/UHD, and
up to 230 feet (70 meters) for 1080p/60 video. The transmitter features a US one-gang, wallplate
form factor, and includes interchangeable black and white wallplates and faceplates. Part of the
Omega™ Series of integration products for modern AV communications and collaboration, the
OME-EX-WP-KIT-LT is HDCP 2.2 compliant and extends RS-232 control signals. The integrated
USB extension addresses the challenge of connecting between USB devices at remote locations,
and is ideal for software video conferencing and touch or interactive displays. The transmitter
includes a USB 2.0 host interface for a PC, plus a peripheral device such as a speakerphone,
microphone, or keyboard and mouse. The receiver provides two USB interfaces for devices such
as a camera, soundbar, or display.
IMPORTANT: Visit http://www.atlona.com/product/AT-OME-EX-WP-KIT-LT for
the latest rmware updates and User Manual.
1 x AT-OME-EX-TX-WP-LT
1 x White faceplate
1 x White RS-232 cover
1 x White wallplate
1 x Black faceplate
1 x Black RS-232 cover
1 x Black wallplate
4 x Mounting screws (2x course thread, 2x ne
thread)
1 x 3-pin captive screw connector
1 x Installation Guide
1 x AT-OME-EX-RX-LT
1 x 4-pin captive screw connector
2 x Mounting plates
4 x Mounting screws
1 x 48 V DC power supply
Package Contents
Problemløsning Atlona AT-OME-EX-WP-KIT-LT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | AV -sender og transceiver |
| Bredde: | 45.8 mm |
| Dybde: | 67 mm |
| Højde: | 103.5 mm |
| Vægt: | 180 g |
| Produktfarve: | Black, White |
| Understøttede videotilstande: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 90 % |
| HDCP: | Ja |
| Understøttede lydformater: | LPCM, PCM |
| Strømforbrug (typisk): | 11.18 W |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Maksimal opløsning: | 4096 x 2160 pixel |
| Understøttede grafikopløsninger: | 2048 x 1080,3840 x 2160,4096 x 2160 |
| Forbindelsesteknologi: | Ledningsført |
| LED-indikatorer: | Ja |
| Strømkilde type: | USB |
| Antal USB-porte: | 2 |
| Farvedybde: | 24 Bit |
| Maksimal overførselsafstand: | 70 m |
| HDMI-version: | 2.0 |
| USB-stik type: | USB Type-A, USB Type-B |
| HSMI-indgang: | 1 |
| RJ-45 indgangs-porte: | 1 |
| RS-232 indgangsporte: | 1 |
| HDCP-version: | 2.2 |
| HDBaseT-port: | Ja |
| Understøttede kabeltyper: | Cat5e, Cat6, Cat6a, Cat7 |
