Side 1/12
1
Installation Guide
AT-OME-EX-TX-WPC
Omega
™
4K/UHD
Wallplate Transmitter for USB-C with HDBaseT Output
and USB
AT-OME-EX-TX-WPC
The Atlona AT-OME-EX-TX-WPC is an HDBaseT transmitter with USB-C input. It sends
video up to 4K/60 4:2:0, plus embedded audio, control, and USB over distances up to 330
feet (100 meters). It features a US one-gang, Decora-style wallplate form factor, and includes
interchangeable black and white wallplates and faceplates. Part of the Omega™ Series of
integration products for modern AV communications and collaboration, the OME-EX-TX-WPC
is HDCP 2.2 compliant and extends RS-232 control signals. The USB-C input is ideal for AV
interfacing with newer Mac®, Chromebook™, and Windows® PCs, as well as smartphones
and tablets. With a matching HDBaseT receiver, the integrated USB extension addresses the
challenge of connecting between USB devices at remote locations, and is ideal for software
video conferencing and touch or interactive displays. The OME-EX-TX-WPC includes a PC host
interface over USB-C, plus a USB 2.0 interface for a peripheral device such as a speakerphone,
microphone, or keyboard and mouse*. This transmitter is ideal for use with Omega Series
receivers as well as switchers with HDBaseT inputs.
* The AT-OME-EX-TX-WPC is not compatible with the AT-UHD-HDVS-300 system for extending
USB.
IMPORTANT: Visit http://www.atlona.com/product/AT-OME-EX-TX-WPC for
the latest rmware updates and User Manual.
1 x AT-OME-EX-TX-WPC
1 x White faceplate
1 x White Decora
®
wallplate
1 x Black faceplate
1 x Black Decora
®
wallplate
4 x Mounting screws
1 x USB-C to USB-C cable, 2 meters
1 x Installation Guide
Package Contents
Problemløsning Atlona AT-OME-EX-TX-WPC
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | AV sender |
| Bredde: | 45.8 mm |
| Dybde: | 67 mm |
| Højde: | 103.5 mm |
| Vægt: | 180 g |
| Understøttede videotilstande: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 60 % |
| HDCP: | Ja |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 1 |
| Understøttede lydformater: | LPCM, PCM |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Maksimal opløsning: | 4096 x 2160 pixel |
| Understøttede grafikopløsninger: | 2048 x 1080,3840 x 2160,4096 x 2160 |
| Forbindelsesteknologi: | Ledningsført |
| Certificering: | CE, RoHS, FCC |
| LED-indikatorer: | Ja |
| USB version: | 3.2 Gen 1 (3.1 Gen 1) |
| Antal USB-porte: | 2 |
| Farvedybde: | 12 Bit |
| Maksimal overførselsafstand: | 100 m |
| USB-stik type: | USB Type-A, USB Type-C |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte: | 1 |
| RS-232 indgangsporte: | 1 |
| HDCP-version: | 1.4/2.2 |
| HDBaseT-port: | Ja |
| Understøttede kabeltyper: | Cat5, Cat6, Cat6a, Cat7 |
| RJ-45 udgangs-porte: | 1 |
| Tovejs: | Ja |
