Side 1/12
1
Installation Guide
AT-OME-EX-RX
Omega™ 4K/UHD
HDMI Over HDBaseT Receiver with USB, Control, and PoE
AT-OME-EX-RX
The Atlona AT-OME-EX-RX is an HDBaseT receiver for video up to 4K/60 4:2:0, plus embedded
audio, control, Ethernet, and USB over distances up to 330 feet (100 meters). Part of the
Omega™ Series of integration products for modern AV communications and collaboration,
the OME-EX-RX is HDCP 2.2 compliant and receives IR, RS-232, and IP control signals. With
a matching HDBaseT transmitter, the integrated USB extension is ideal for software video
conferencing and the use of touch or interactive displays. The OME-EX-RX includes two USB
interfaces for devices such as a camera or display. This receiver is ideal for use with Omega
Series transmitters as well as switchers with HDBaseT outputs. Also available is the OME-EX-
KIT which includes the OME-EX-TX and OME-EX-RX.*
* The AT-OME-EX-RX is not compatible with the AT-UHD-HDVS-300 system for extending USB.
IMPORTANT: Visit http://www.atlona.com/product/AT-OME-EX-RX for the
latest rmware updates and User Manual.
1 x AT-OME-EX-RX
1 x Captive screw connectors, 4-pin
2 x Mounting plates
4 x Mounting screws
1 x 48 V DC power supply
1 x Installation Guide
Package Contents
Problemløsning Atlona AT-OME-EX-RX
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | AV-modtager |
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Bredde: | 109 mm |
| Dybde: | 127 mm |
| Højde: | 26 mm |
| Vægt: | 430 g |
| Understøttede videotilstande: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 90 % |
| HDCP: | Ja |
| Ethernet LAN: | Ja |
| Understøttede lydformater: | LPCM |
| Strømforbrug (typisk): | 18.76 W |
| Driftstemperatur (T-T): | -18 - 50 °C |
| Maksimal opløsning: | 4096 x 2160 pixel |
| Understøttede grafikopløsninger: | 2048 x 1080,3840 x 2160,4096 x 2160 |
| Forbindelsesteknologi: | Ledningsført |
| Lyd-output kanaler: | 7.1 kanaler |
| Certificering: | CE, RoHS, FCC |
| LED-indikatorer: | Ja |
| Strømkilde type: | DC |
| Antal USB-porte: | 3 |
| Farvedybde: | 24 Bit |
| Modulation: | PCM |
| Maksimal overførselsafstand: | 100 m |
| USB-stik type: | Mini-USB A, USB Type-A |
| Antal HDMI-udgange: | 1 |
| RS-232 indgangsporte: | 1 |
| HDCP-version: | 2.2 |
| Understøttede kabeltyper: | Cat5e, Cat6, Cat6a, Cat7 |
| RJ-45 udgangs-porte: | 1 |
| HDBaseT certificeret: | Ja |
