RT-AC65
Dual band AC WiFi Router
Quick
Start Guide
Package contents
A quick look at RT-AC65
RT-AC65 Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
LAN LED Power (DCIN) port
WAN (Internet) LED Power switch
2.4GHz LED USB 3.0 port
5GHz LED WAN (Internet) port
Power LED LAN 1 ~ 4 ports
WPS button
NOTES:
• Use only the adapter that came with your package. Using other
adapters may damage the device.
• Specifications:
DC Power adapter DC Output: +12V with 2A current
Operating Temperature 0~40
oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
For optimal wireless transmission between the wireless router and connected wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum wireless coverage for the network devices.
• Keep the wireless router away from metal obstructions and away from direct sunlight.
• Always update to the latest firmware. Visit the ASUS website at to get the latest firmware updates. http://www.asus.com
Position your wireless router
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a
battery backup, remove the battery.
NOTE: If you are using DSL for Internet,
you will need your username/password
from your Internet Service Provider (ISP)
to properly configure the router.
2. Connect your modem to the router with
the bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights
to ensure the connection is active.
Setting up your RT-AC65
2. The web GUI launches automatically when you open a web
browser. If it does not auto-launch, enter http://router.asus.com.
3. Log into the Web GUI. By default, the login username and
password for your wireless router’s Web GUI is . admin
4. Set up a password for your router to prevent unauthorized access.
LINE RES E T PWRLAN
a
d
c
b
1. Plug your router into a power outlet and power it on.
Connect the network cable from your computer to a LAN
port on your router.
You can set up your RT-AC65 via wired or wireless connection.
A. Wired connection
1. Plug your router into a power outlet and power it
on.
B. Wireless connection
LINE RESET PWRLAN
a
c
b
2. Connect to the network
with SSID shown on
the product label on the
back side of the router.
For better network
security, change to
a unique SSID and
assign a password.
ASUS router
Wi-Fi Name (SSID): ASUS_XX
* refers to the last XX
two digits of the
MAC address. You
can find it on the
label on the back of
your RT-AC65.
Problemløsning Asus RT-AC65
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 110 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Vægt: | 467 g |
| Produktfarve: | Black, Grey |
| Produkttype: | Bordplade router |
| USB-port: | Ja |
| Ethernet LAN-porte (RJ-45): | 4 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 1 |
| Ethernet LAN: | Ja |
| Wi-Fi-standarder: | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Intern hukommelse: | 128 MB |
| Ethernet WAN: | Ja |
| DSL WAN: | Ingen |
| SIM-kort slot: | Ingen |
| 3G/4G kompatibilitet USB-modem: | Ingen |
| Wi-Fi-bånd: | Dual-band (2,4 GHz / 5 GHz) |
| Bedste Wi-Fi standard: | Wi-Fi 5 (802.11ac) |
| WLAN dataoverførselshastighed (maks): | 1300 Mbit/s |
| Ethernet LAN-grænsefladetype: | Gigabit Ethernet |
| Kabelteknologi: | 10/100/1000Base-T(X) |
| 3G: | Ingen |
| 4G: | Ingen |
| 5G: | Ingen |
| Antennedesign: | Ekstern |
| Antenner, antal: | 3 |
| LED-indikatorer: | LAN, Power, WAN |
| Strømkilde type: | Vekselstrøm |
| Udgangsspænding: | 12 V |
| Udgangsstrøm: | 1.5 A |
| Flashhukommelse: | 128 MB |
