QR-GOLD
Installation Instructions
The Gold Mount
®
Battery System is an advanced design of the popular Anton/Bauer
®
Snap-On
®
Mounting System currently
being used by virtually every professional video camera manufacturer in the world.
FEATURES
CAUTION: Open + and – wires inside bracket. DO NOT attach battery without terminating wires.
1. Cam action latch for improved ease of battery loading and removal. Red label below latch indicates battery is not fully
latched, eliminating inadvertent battery unloading.
2. Safety lock provides user with a safety for the latch mechanism. Will allow battery to remain in the fully latched position in
the event the mounted battery is shocked or latch mechanism is accidentally depressed. Green label below safety
indicates locked “shoot” position.
(continued)
4
5
6
1
2
3
Approved Copy
