Thank you for purchasing the LED Beacon by American DJ®. You have either purchased the B6R
LED (Red Beacon) or B6B LED (Blue Beacon). Please read the user instructions before using your new
LED Beacon.
American DJ® LED Beacon
American DJ® los angeles, ca. 90058
Specications:
Power Supply: 120V
Power Consumption: 25W Max
Weight: 1.85 lbs/0.84Kgs
Dimensions: 7.2” x 6.85” x 6.85”
For single bar clockwise rotation put dipswitches 8 & 9 in the On positions and dipswitch 10 in the Off position.
For single bar counter clockwise rotation put dipswitches 8 & 10 in the On positions and dipswitch 9 in the Off position.
For two opposite rows clockwise rotation put dipswitch 8 in the On position and dipswitches 9 & 10 in the Off positions.
For two opposite rows counter clockwise rotation put dipswitches 9 & 10 in the On positions and dipswitch 8 in the Off
position.
For four opposite rows clockwise rotation put dipswitch 9 in the On position and dipswitches 8 & 10 in the Off position.
To turn all LED’s full on put dipswitch 10 in the On positions and dipswitches 8 & 9 in the Off position.
To turn all LED’s off dipswitches 8, 9, & 10 must be either in the On or Off positions.
Dipswitches 8 - 10 allow you to select a program and the rotation direction.
Dipswitches 1 - 7 allow you to control the rotation speed.
When dipswitches 1-6 are in the Off position and dipswitch
7 is in the On position, the rotation speed will be at the
maximum speed
When dipswitches 1-7 are all in the On position, the
rotation speed will be at the slowest.
When dipswitches 1-3 are all in the Off position,
and dipswitches 4-7 are in the On position, the
rotation speed will be at medium speed.
8 Rows of LED’s
