©American Audio® - www.AmericanAudio.us -
LOS ANGELES, CA. 90040
Model: Active DBM
SPECIFICATIONS:
Power Consumption: 10W
Power: 12V DC 500mA
Weight: 1.75 lbs. / 0.85
Size: 1 3/4” (L) x 19” (W) x 1 3/4” (H)
19 in. single space rack mount.
Thank you for purchasing this ©American Audio® product. For your convenience this products
ready to be used, there is no assembly required. Please read the following instructions before
installing or using your new unit.
Operating Instructions:
1. Plug in proper AC adapter.
2. Connect music signal to Left and Right input jacks, must be pre-amp level.
3. Turn the power switch on.
4. Adjust L and R audio controls to desired response
5. This unit has BAR and DOT display modes.
BAR mode: Set switch to BAR position, LEDs will glow from -57dB to 0dB according to signal
strength.
DOT mode: Set Mode switch to DOT position, only two LEDs glow and chase from left to right
according to audio level variety.
Sensitivity Adjustment: For low level and high level signals, adjust accordingly.
NOTE: This is not a Line Transformer, do not plug an RCA (unbalanced source) and then use XLR
outs or vice versa.
User Instructions
Active DBM
