PCE-5B05V-30B1E Startup Manual 1
Before you begin installing your card, please make sure
that the following items have been shipped:
• One 2-port USB cable p/n: 1700002204
• PCE-5B05V-30B1E startup manual
• M4*6*0.7 round screws (5 pcs) p/n: 1939000410
• Warranty Card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B05V-30B1E Backplane: 5-slot BP for 2U Chas-
sis, 1 x PICMIG 1.3, 1x PCIe, 3 x 64-bit PCI-X
Startup Manual
Standard Functions
• PICMIG 1.3 slots:
PCE-5B05V-30 supports PCE-5xxx CPU boards
• PCIe slots:
PCE-5B05V-30 supports one PCIe x16 slot
• 64-bit PCI-X:
Three 64 Bit / 100 MHz PCI-X slots
• USB (2.0) support:
Four Universal Serial Bus ports to backplane
Mechanical and Environment
• Dimensions: 80.01 x 325 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
• Power requirements: Refer to the CPU board, add-on
card and peripherals
• Operating temperature: 0 ~ 60° C
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/Network/
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B05V-30B1E series.
Part No. 200K5B0503 4th Edition
May 2016
